PRODUCTS >> ATV/UTV |
|
|
|
|
|
| SPECIFICATION |
| Engine |
|
| Type: |
Single Cylinder, Air-Cooled, 4-Stroke |
| Ignition Mode: |
CDI |
| Compression Proportion: |
9.1:1 |
| Start Mode: |
Electric |
| Fuel Tank Capacity: |
7.8L |
| Transmission Mode: |
Chain |
| Displacement: |
106.7 |
| Power: |
5.5kW/8000rpm |
| Max. Torque: |
6.6N.m/5750rpm |
| Min. Ground Clearance: |
100mm |
| Max. Speed |
≥45km/h |
| Power Source: |
12V9Ah |
| Transmission: |
4Gears with Reverse Gear, Manual Clutch |
| Cylinder Size: |
52.4x49.5 mm |
| Engine Oil: |
7.8L |
| Lubrication: |
Press Splash |
| Parking Trig: |
Mechanical Lock |
| Gas Cylinder Number: |
1 |
| Chassis |
|
| Front Wheels: |
19×7-8 |
| Rear Wheels: |
18×9.5-8 |
| Break Type : |
Disc/Disc or Drum/Disc |
| Front Hanging: |
Double Arm-Swing |
| Rear Hanging: |
Integral |
| Dimensions |
|
| Product Dimensions : |
1540×860×950mm |
| Carton Dimensions: |
1400x855x760mm |
| Wheelbase: |
1040mm |
| Seat Height: |
650mm |
| Vehicle Weight: |
130kg |
| Load Capacity: |
125kg |
| Climbing Degree: |
≥20° |
| Min. Turning Radius: |
2400 mm |
| Max. Number of Riders: |
1 |
| Others |
|
| Conveyance: |
Qty/20"GP:31units |
| Qty/40"GP:64units |
| Qty/40"HQ:66units |
| Color: |
Red/Yellow/Blue/Green/Black |
| Port Of Shipment |
Chongqing, China |
| Package |
Outer Carton with Inner Iron Frame, weight is about 20-30kgs Carton Size: 1400x855x760mm |
| Payment Terms: |
30% T/T deposit, 70% balance before the shippment. |
| Delivery Time: |
|
| Min. Order |
One 40" HQ Container (Can mix different models in one 40" HQ Container) | |
|
|
|
