PRODUCTS >> ATV/UTV |
|
|
|
|
|
| SPECIFICATION |
| Engine |
|
| Type: |
Single Cylinder, Air-Cooled, 4-Stroke, Automatic Clutch |
| Ignition Mode: |
CDI |
| Compression Proportion: |
8.7:1 |
| Start Mode: |
Electric |
| Fuel Tank Capacity: |
12L |
| Transmission Mode: |
Axis |
| Displacement: |
229.6ml |
| Power: |
10kW/7000-8000rpm |
| Max. Torque: |
15N.m/4500-6500rpm |
| Min. Ground Clearance: |
160 mm |
| Max. Speed |
≥66km/h |
| Power Source: |
12V14Ah |
| Transmission: |
5Gears with Reverse Gear |
| Cylinder Size: |
71x58mm |
| Engine Oil: |
1.5L |
| Lubrication: |
Press Splash |
| Parking Trig: |
Mechanical Lock |
| Gas Cylinder Number: |
1 |
| Chassis |
|
| Front Wheels: |
23×7-10 |
| Rear Wheels: |
22×10-10 |
| Break Type : |
Hydraulic Disc/Drum |
| Front Hanging: |
Single Arm-Swing |
| Rear Hanging: |
Integral |
| Dimensions |
|
| Product Dimensions : |
1880×1050×1160mm |
| Carton Dimensions: |
1960×1100×850mm |
| Wheelbase: |
1160mm |
| Seat Height: |
810mm |
| Vehicle Weight: |
226kg |
| Load Capacity: |
165kg |
| Climbing Degree: |
≥25° |
| Min. Turning Radius: |
2200mm |
| Max. Number of Riders: |
1 |
| Others |
|
| Conveyance: |
Qty/20"GP:12units |
| Qty/40"GP:24units |
| Qty/40"HQ:36units |
| Color: |
Red/Black/Blue/Green/Camouflage |
| Port Of Shipment |
Chongqing, China |
| Package |
Outer Carton with Inner Iron Frame, weight is about 20-30kgs Carton Size: 1960×1100×850mm |
| Payment Terms: |
30% T/T deposit, 70% balance before the shippment. |
| Delivery Time: |
|
| Min. Order |
One 40" HQ Container (Can mix different models in one 40" HQ Container) | |
|
|
|
Zongshen Engines
