| SPECIFICATION |
| Engine |
|
| Type: |
Single Cylinder,Water-cooling,Vertical,4-StrokeInner Reverse |
| Ignition Mode: |
CDI |
| Compression Proportion: |
10:1 |
| Start Mode: |
Electric |
| Fuel Tank Capacity: |
13L |
| Transmission Mode: |
Chain |
| Displacement: |
226ml |
| Power: |
10kW/7000-8000rpm |
| Horse Power: |
15N.m/4500-6500rpm |
| Max. Torque: |
19N.m（4500rpm） |
| Min. Ground Clearance: |
165mm |
| Max. Speed |
≤72km/h |
| Power Source: |
12V14Ah |
| Transmission: |
5 Gears,with Reverse,Manual Clutch |
| Cylinder Size: |
73×65mm |
| Engine Oil: |
1.4L |
| Lubrication: |
SAE15W-40/SF |
| Parking Trig: |
Mechanical Lock |
| Gas Cylinder Number: |
1 |
| Chassis |
|
| Front Wheels: |
23×7-10 |
| Rear Wheels: |
22×10-12 |
| Break Type(F/R): |
Disc/Disc |
| Front Hanging: |
Double Arm-Swing |
| Rear Hanging: |
Integral |
| Dimensions |
|
| Product Dimensions: |
1900×1250×1140mm |
| Carton dimensions: |
1710X1120X860mm |
| Wheelbase: |
1270mm |
| Seat Height: |
880mm |
| Vehicle Weight: |
200kg |
| Load Capacity: |
165kg |
| Climbing Degree: |
≥25° |
| Min. Turning Radius: |
2400mm |
| Max. Number of Riders: |
1 |
| Others |
|
| Conveyance: |
Qty/12"GP: 12units |
| Qty/28"GP: 28units |
| Qty/40"HQ: 42units |
| Color: |
Red/Black/Blue |
| Payment Terms: |
30% T/T deposit, 70% balance before the shippment. |
| Delivery Time: |
15-30days after receiving the 30% T/T deposit or L/C at sight |
| Min. Order |
One 40" HQ Container (Can mix different models in one 40" HQ Container) |
| Warranty |
Six months for the engine and chain, if buy with 40" HQ containers, we attach 1% free parts | |
|
|
|
