| SPECIFICATION |
| Engine |
|
| Type: |
Single cylinder,DOHC,4-VALVES,water-cooled,4-stroke,manual clutch. |
| Ignition mode: |
CDI |
| Compression ratio: |
10:1 |
| Start mode: |
Electric |
| Fuel tank capacity: |
12L |
| Transmission mode: |
Shaft drive |
| Displacement: |
272mL |
| Power: |
20kw/7000-8000rpm |
| Horse Power: |
HP |
| Max.torque: |
23N.m/4500-6500rpm |
| Min.ground clearance: |
160mm |
| Max. speed |
≥80 km/h |
| Power source: |
12V,14 Ah |
| Transmission: |
5 gears with inner reverse gear |
| Cylinder size: |
71x58mm |
| Engine oil: |
1.5 L |
| Lubrication: |
SF-15W/40 or the same grade |
| Parking brake: |
Mmechanical lock |
| Gas cylinder number: |
1 |
| Chassis |
|
| Front wheels: |
22×7-10 |
| Rear wheels: |
22×10-10 |
| Break type (F/R): |
Front and rear drum brakes |
| Front suspension: |
Single arm-swing |
| Rear suspension: |
Independent axle |
| Dimensions |
|
| Product dimensions : |
1930x1040x1310mm |
| Carton dimensions: |
1960x1100x850mm |
| Wheel base: |
1160 mm |
| Seat Height: |
830 mm |
| Vehicle weight: |
226 kgs |
| Load capacity: |
165 kgs |
| Climbing angle: |
≥ 25 ° |
| Min.turning radius: |
2200 mm |
| Max.number of riders: |
1 |
| Others |
|
| Container Loading |
Qty/20’ GP: 12 units |
| |
| Qty/40’ GP: 24 units |
| |
| Qty/40’ HQ: 36 units |
| Color: |
red/black/blue/army green/camouflage green |
| Payment Terms: |
30% T/T deposit, 70% balance before the shippment. |
| Delivery Time: |
within 25 days after receive the advance payment | |
|
|
|
